Product Description
Briggs & Stratton general purpose horizontal shaft engines are built to be tough, reliable and efficient.
This XR550 engine is designed for frequent use in demanding work environments. This type of engine is often found used in applications such as cement mixers, cylinder mowers, small tillers, etc.
Model Number: 0831320011F1BF7001
Series: XR550 OHV
Cylinder/s: Single
Cylinder type: Cast Iron Sleeved
Power: 3.5 HP Gross* (2.6 kW @ 3600 rpm**)
Capacity: 127 cm³/cc
Fuel type: Petrol (4-Stroke)
Cooling system type: Air
Crankshaft position: Horizontal
Crankshaft type: Straight (Forged Iron)
Crankshaft diameter: 19.05 mm (3/4")
Crankshaft length: 62mm (2 7/16 ")
Flywheel type: Heavy
Throttle type: Variable
Recoil starter: Yes (10 O'Clock)
Electric starter: No
Priming System: Manual Choke
Fuel pump: No
Oil filter: No
Oil Alert: Yes
Muffler: Yes (Lo-Tone)
Fuel tank: Yes
Fuel tank capacity: 2 ltr
Oil capacity: 0.6 ltr*
Dry weight: 13.4 Kg
Dimensions: 263 mm x 347 mm x 328 mm*
Warranty: 2 Years Consumer and Commercial (T's & C's apply)
Alternative to: 083132-0233-H5, 083132-0249-H5
* Approximately
** All power levels are stated gross kilowatt per SAE J1940 as rated by Briggs & Stratton
FREE Engine Oil to commission the engine is included.
Always read owners manual prior to commissioning engine. Damage caused by improper installation are not warrantable.
Shipping restrictions may apply. Please contact us for confirmation if the required delivery destination is outside of the UK.
IMPORTANT NOTE: If you are not completely sure that this engine will suit your intended application, please contact us with your original engine details first, (in the case of Briggs, the Model, Type and Code numbers). One of our Briggs trained staff will then be able to confirm whether this engine is suitable, and if not, assist with identification of the correct engine for your requirements.
