Product Description
The Briggs and Stratton 850PXi Series™ I/C® engines represent the ultimate durability package. These engines provide all the performance benefits of the E Series engine family and in addition deliver the extended durability professional users are looking for.
As an I/C engine, (Industrial/Commercial), this engine features a Cast Iron cylinder sleeve, this is designed to significantly enhance the longevity of the engine for those who use their equipment day-in and day-out.
Model Number: 123P020029H5YY0001
Fits selected moodels of Hayter BBC mowers. (If you're unsure if this model is suitable as a replacement for your orignal engine please contact us to confirm prior to ordering).
Series: 850PXi I/C OHV
Cylinder/s: Single
Cylinder type: Cast Iron Sleeved
Power: 11.53 Nm @ 2600 rpm** / 8.5lb/Ft
Capacity: 190 cm³/cc
Fuel type: Petrol (4-Stroke)
Cooling system type: Air
Crankshaft position: Vertical
Crankshaft type: Stepped
Flywheel type: Heavy
Flywheel brake: No
Governor type: Mechanical
Throttle type: Remote variable speed
Top No Load rpm: 2800 +/- 100
Recoil starter: Yes
Electric starter: No
Priming System: Ready Start (Autochoke)
Fuel pump: No
Oil filter: No
Low oil cut off: No
Muffler: Yes (Performance with tubular outlet)
Fuel tank: Yes
Fuel tank capacity: 1 ltr
Oil capacity: 0.6 ltr*
Dry weight: 10.8 Kg
Dimensions: 399 mm x 338 mm x 253mm*
Replaces: 123P020014H5YY0001
* Approximately
** All torque levels are stated gross Nm per SAE J1940 as rated by Briggs & Stratton.
FREE Engine Oil to commission the engine is included.
Always read owners manual prior to commissioning engine. Damage caused by improper installation are not warrantable.
Shipping restrictions may apply. Please contact us for confirmation if the required delivery destination is outside of the UK.
IMPORTANT NOTE: If you are not completely sure that this engine will suit your intended application, please contact us with your original engine details first, (in the case of Briggs, the Model, Type and Code numbers). One of our Briggs trained staff will then be able to confirm whether this engine is suitable, and if not, assist with identification of the correct engine for your requirements.
